FTTH Mini ONU 1 GE Gigabit Ethernet 1 Pon Port GPON Xpon ONT Fiber Optic Network Unit
SKU: 5487FB8/11-1-1
Inclusive of all taxes
Razorpay Verified Secure Payment
Payment Methods
Trusted by Businesses Across India
Genuine Products
Sourced from authorized channels
Quality Checked
On every order, every time
PAN India Delivery
Shipped nationwide
Warranty
Where applicable, per manufacturer
Highlights
-
1 GE Gigabit Ethernet ONT 1 Pon Port GPON ONU Xpon Fiber Home HTTH Xgpon ONU
Product Introduction：
G55 is a single port GPON SFU, which provides users with uplink optical access, uses optical fiber wiring, signal transmission is not affected by electromagnetic interference, low bit error rate, small delay, high transmission quality, and better reflects broadband performance. The product is small, green, low-power, RoHS compliant, cost-effective and easy to install and maintain. White casing is adopted in appearance, which is simple and bright.
Product Characteristics：
- GPON SFU,stable and low latency.
- Small, green, low-power, RoHS complian.
- Cost-effective and easy to install and maintai
Specifications
| SKU | 5487FB8/11-1-1 |
|---|
Description
XPon Mini ONU Interface Function
- 1 *G/EPON interface：SC/UPC/APC interface，Comply with GPON and EPON standards
- 1* Ethernet interface：10Mbps/100Mbps/1000Mbps，RJ-45，Comply IEEE802.3–2005 standards
| LED | PWR+PON/LOS+LAN |
| Port | 1*RJ45(GE) |
| 1*Reset | |
| 1*SC/APC (or SC/UPC) | |
| 1*DC | |
| Size | 79.5*74.7*22mm(L*W*H) |
| Power Consumption | ≤8W |
| Ethernet Port | Ethernet port-based VLAN tags and tag removal |
| VLAN transparent and aggregation | |
| MAC address learning | |
| 10/100/1000Mbps Auto negotiation |
Solfware Parameters
| G/EPON | ITU-T G.984.1-4 |
| IEEE 802.3ah | |
| 15 TCONTs /256GEM ports | |
| 8 Egress queues per TCONT at least | |
| VLAN or VLAN plus priority gem mapping mode | |
| SN/LOID/SN+ Password authentication | |
| Performance monitoring: eth/Gem port | |
| Dying gasp | |
| Layer 2 Features | MAC learning (SVL)/aging |
| Support max frame length to1518 bytes | |
| VLAN tagging for untagged packets | |
| Support VLAN 1-4094 | |
| VLAN transparent/translation | |
| Multicast | IGMP v2 (RFC 2236) and IGMP v3 (RFC 3376) |
| IGMP snooping | |
| Management | OMCI/Web UI |
Environment
| Operate Temperature | 0℃~45℃ |
| Storage Temperature | -20℃~70℃ |
| Operating Humidity | 5%～95% non-condensing |
| Power Supply | 12V/0.5A |
